Specifications

PRICING

Price	Standard
Price - Warranty (Months)	0

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Torque RPM	8500
Engine - Cooling	Liquid
Engine - Valves	4
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	OHV
Engine - Bore (mm)	76.8
Engine - Bore (in)	3.02
Engine - Stroke (mm)	53.8
Engine - Stroke (in)	2.12
Engine - Displacement (cc)	249
Engine - Displacement (ci)	15.2
Engine - Compression Ratio	13.2:1
Engine - Starter	Kick
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Fuel Injector	Yes
Carburetion - Fuel Injector Size (mm)	50
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	5
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Wheelbase (in)	58.2
Dimensions - Wheelbase (mm)	1478.3
Dimensions - Ground Clearance (in)	12.8
Dimensions - Ground Clearance (mm)	325.1
Weight	Standard
Weight - Wet Weight (lbs)	226
Weight - Wet Weight (kg)	102.5
Capacities	Standard
Capacities - Fuel Capacity (gal)	1.5
Capacities - Fuel Capacity (l)	5.7
Performance	Standard

EXTERIOR

Construction	Standard
Construction - Frame	Aluminum
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Belt Guard	No
Exterior Guards - Hand Guards	No
Exterior Guards - Brush Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Exterior Covers - Side Cover	Yes
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard
Skid Plate	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Inverted Fork
Front Suspension - Front Suspension Size (in)	1.9
Front Suspension - Front Suspension Size (mm)	48
Front Suspension - Front Travel (in)	12.4
Front Suspension - Front Travel (mm)	315
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	Yes
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Front Suspension Brand Name	Showa®
Front Suspension - Steering Damper	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Suspension Size (in)	2
Rear Suspension - Rear Suspension Size (mm)	50
Rear Suspension - Rear Travel (in)	12.6
Rear Suspension - Rear Travel (mm)	320
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	Pro Link®
Rear Suspension - Rear Suspension Material	Aluminum
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubed
Wheels - Chromed	No
Tires	Standard
Tires - Tire Brand	Dunlop®
Tires - Front Tire Width	80
Tires - Front Tire Aspect Ratio	100
Tires - Front Wheel Diameter	21
Tires - Rear Tire Width	100
Tires - Rear Tire Aspect Ratio	90
Tires - Rear Wheel Diameter	19
Tires - Front Tire (Full Spec)	Dunlop® 80/100 R21 742FA
Tires - Rear Tire (Full Spec)	Dunlop® 100/90 R19 D756

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Disc
Brakes - Front Brake Diameter (in)	9.5
Brakes - Front Brake Diameter (mm)	240
Brakes - Rear Brake Type	Disc
Brakes - Rear Brake Diameter (in)	9.5
Brakes - Rear Brake Diameter (mm)	240

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	38
Seat Specifications - Seat Height (mm)	965.2
Seat Specifications - Number Of Seats	1
Seat Backrest - Backrest Logo Plate	No

CONVENIENCE

Adjustable Handlebars	Standard
Adjustable Levers	Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
